Low cost Long Life Time Brushless Dc Planetary Gear Motor BLDC Motor 12v 24v 36v 48v With Helical Gear High Torque

Low cost Long Life Time Brushless Dc Planetary Gear Motor BLDC Motor 12v 24v 36v 48v With Helical Gear High Torque

Products - Brushless DC Planetary Gear Motor
  • Torque
    Upto 20Nm
  • Power
    10w 20w 50w 100w 200w 300w
  • Speed
    Customizable
  • Voltage
    12V, 24V, 36v ,48v, 230V
  • Place of Origin
    CHINA
  • Brand Name
    SMART AUTOMATION
  • Certification
    ROHS CE ISO9001
  • Model Number
    42JXLG200K. 57HBL
  • Minimum Order Quantity
    100
  • Packaging Details
    STANDARD EXPOTR PACKAGE
  • Delivery Time
    45DAYS
  • Payment Terms
    Western Union, T/T
  • Supply Ability
    100000PCS

Low cost Long Life Time Brushless Dc Planetary Gear Motor BLDC Motor 12v 24v 36v 48v With Helical Gear High Torque

  • Low cost Long Life Time Brushless Dc Planetary Gear Motor BLDC Motor 12v 24v 36v 48v With Helical Gear High Torque
  • Low cost Long Life Time Brushless Dc Planetary Gear Motor BLDC Motor 12v 24v 36v 48v With Helical Gear High Torque
  • Low cost Long Life Time Brushless Dc Planetary Gear Motor BLDC Motor 12v 24v 36v 48v With Helical Gear High Torque
Get Price Contact Now



42JXLG200K. 57HBL Series Brushless Dc Planetary Gear Motor



Motor Technique Specification

Model 57HBL01A 57HBL02A 57HBL03A 57HBL04A
Number of phase 3
Number of pole 4 (; Option for 8)
Voltage V 24v(Option for 12v up to 230vdc)
No load speed rpm 5200 5200 5300 5400
Rated torque Nm 0.14 0.28 0.43 0.49
Rated Speed rpm 4000 4000 4000 4000
Rated Current A 3.5 6.8 10.5 11.9
Rated Power W 58.64 117.28 180.10 205.24
Weight Kg 0.5 0.8 1.1 1.5
Length mm 55 75 95 115



Planetary Gearbox Specification Gearbox Model: 42JXLG200K

Features: Low noise,long life gearbox, first stage helical gear, segmented design,planetary gear plus needle bearing, large torque output, code numbers L and G are used in the model.



Low cost Long Life Time Brushless Dc Planetary Gear Motor BLDC Motor 12v 24v 36v 48v With Helical Gear High Torque 0



Reduction ratio Exact reduction ratio

Rated tolerance

torque

Max momentary

tolerance torque

 Efficiency L (mm) Weight(g)
1/3.71 1/5.18 1/3.71 1/5.18 2.0 N.m Max. 5.0 N.m 90 % 34.2±0.5 265

1/14 1/19

1/22 1/27

1/13.76 1/19.22

1/22.21 1/26.83

 8.0 N.m Max. 20 N.m 81 % 49.6±0.5 380

1/49 1/59 1/68

1/82 1/95 1/115

1/48.83 1/58.86 1/68.28

1/82.30 1/95.47 1/115.08

 16 N.m Max. 40 N.m 73 % 62.0±0.5 475

1/181 1/218 1/253

1/305 1/354 1/426

1/495 1/596

1/180.96 1/218.12 1/253.03

1/304.99 1/253.80 1/426.46

1/494.71 1/596.31

 20 N.m Max. 50 N.m 66 % 74.4±0.5 570



Dimensions

Low cost Long Life Time Brushless Dc Planetary Gear Motor BLDC Motor 12v 24v 36v 48v With Helical Gear High Torque 1



Wiring Diagram

Low cost Long Life Time Brushless Dc Planetary Gear Motor BLDC Motor 12v 24v 36v 48v With Helical Gear High Torque 2



Tags:

Geared Brushless DC Motor

Brushless DC Worm Gear Motor

brushless dc gearmotor
