NMRV050.80BL High Power Brushless DC Wrom Gear Motor with RV050 Gearbox 12vdc 24vdc 36vdc 48vdc Up To 400W

NMRV050.80BL High Power Brushless DC Wrom Gear Motor with RV050 Gearbox 12vdc 24vdc 36vdc 48vdc Up To 400W

  • Highlight

    NMRV050.80BL dc gear motor 24v

    ,

    dc gear motor 24v 60Nm 12v

    ,

    NMRV050.80BL High Power Brushless Dc Motor

  • Warranty
    3years
  • Port
    Shanghai
  • Current
    Customized For Different Power
  • Speed(RPM)
    Customed
  • Continuous Current(A)
    Customed
  • Usage
    Car, Electric Bicycle, FAN, Home Appliance, Michine
  • Type
    SERVO MOTOR
  • Torque
    Customed
  • Construction
    Series Wound
  • Commutation
    Brushless
  • Protect Feature
    Drip-proof
  • Place of Origin
    Changzhou CHINA
  • Brand Name
    SMART AUTOMATION
  • Certification
    CE
  • Model Number
    OEM
  • Minimum Order Quantity
    50
  • Price
    To be negotiated
  • Packaging Details
    To be negotiated
  • Delivery Time
    To be negotiated
  • Payment Terms
    D/A, T/T, L/C,D/P
  • Supply Ability
    10000 Piece/Pieces per Month

NMRV050.80BL High Power Brushless DC Wrom Gear Motor with RV050 Gearbox 12vdc 24vdc 36vdc 48vdc Up To 400W

NMRV050.80BL High Power Brushless Dc Motor with Worm Gear Reducer upto 60Nm, 12v 24v 36v 48v upto 400W



NMRV050.80BL Brushless Dc Worm Gear Motor











80BL Technique Specification

Model 80RBL01M 80RBL02M 80RBL03M 80RBL04M 80RBL05M
Number of phase 3
Number of pole 8
Voltage V 24v (Option for 12v 36v 48v 60v)
No load speed rpm 3100 3100 3100 3100 3100
Rated torque Nm 0.4 0.8 1.2 1.4 1.8
Rated Speed rpm 2200 2200 2200 2200 2200
Rated Power W 92 185 277 324 416
Length mm 60 80 100 115 135
