42ZYT03 GR42x40 15w 20w 3100rpm 3500rpm 12 Volt 24 Volt PM DC Motor PMDC Motor 12volt 24volt 36volt 40volt
-
Highlight
GR42x40 permanent magnet dc motor
,GR42x40 pmdc motor
,20w 12 volt pmdc motor
-
Warranty3years
-
PortShanghai
-
CurrentCustomized
-
Speed(RPM)3100~3700rpm
-
Continuous Current(A)Customed
-
UsageCar, Electric Bicycle, FAN, Home Appliance, Machineary
-
TypeMicro Motor
-
Torque57mNm
-
ConstructionPermanent Magnet
-
CommutationBrushless
-
Protect FeatureDrip-proof
-
EfficiencyIE 1
-
Place of OriginChangzhou CHINA
-
Brand NameSMART AUTOMATION
-
CertificationCE
-
Model NumberOEM
-
Minimum Order Quantity50
-
PriceTo be negotiated
-
Packaging DetailsTo be negotiated
-
Delivery TimeTo be negotiated
-
Payment TermsD/A, T/T, L/C,D/P
-
Supply Ability10000 Piece/Pieces per Month
42ZYT03 GR42x40 15w 20w 3100rpm 3500rpm 12 Volt 24 Volt PM DC Motor PMDC Motor 12volt 24volt 36volt 40volt
42ZYT03Z equivalent to GR42x40 15w~20w 12 volt 24 volt permanent magnet dc motor
Motor technical parameter:
Shaft HRC 36~40 ; NMB ball bearing
Hard ferrit magnet, 2- poles
Protection class IP 50
Insulation class: F, operating temperature range:-40°C~+140°C
CE and ROHS certified
Options:
Customized voltage, winding, shaft, mounting, and lead configurations
EMI/RFI suppression circuit; Thermal protection
High temperature Class H insulation
| Model | 42ZYT03Z | |||
| Rated voltage | V dc | 12 | 24 | 40 |
| Continuous rated speed | rpm | 3750 | 3100 | 3400 |
| Continuous rated torque | mN.m | 53 | 57 | 57 |
| Continuous current | A | 2.7 | 1.2 | 0.8 |
| Starting torque | mN.m | 320 | 330 | 360 |
| Starting current | A | 13.2 | 5.68 | 3.97 |
| No load speed | rpm | 4550 | 3800 | 3950 |
| No load current | A | 0.44 | 0.18 | 0.12 |
| Demagnetization current | A | 24 | 10.5 | 6.3 |
| Rotor inertia | Gcm2 | 110 | 110 | 110 |
| Weight of motor | g | 490 | 490 | 490 |
| Motor length | Mm | 85 | 85 | 85 |
